Ford Ranger V SuperCrew (Americas) Raptor 3.0 EcoBoost V6 (405 Hp) 4x4 Automatic technical specifications and fuel economy

Ford  Ranger V SuperCrew (Americas)  Raptor 3.0 EcoBoost V6 (405 Hp) 4x4 Automatic



Ford Ranger V SuperCrew (Americas) Raptor 3.0 EcoBoost V6 (405 Hp) 4x4 Automatic Technical information

  • Engine displacement
    2949 cm3
  • Power
    405 hp
    298 kW
  • Acceleration from 0 to 100 km/h
    N/A
  • Maximum speed
    N/A
  • Kerb Weight
    2415 kg
    5324 lbs
Compare this car with other cars
Ford  Ranger V SuperCrew (Americas)  Raptor 3.0 EcoBoost V6 (405 Hp) 4x4 Automatic  General information General information
Brand : Ford
Model : Ranger
Generation : Ranger V SuperCrew (Americas)
Engine / modification : Raptor 3.0 EcoBoost V6 (405 Hp) 4x4 Automatic
Production start : 2023 year
Production end :
Coupe type : Pick-up
Powertrain Architecture : Internal Combustion engine
Num. of Doors : 4
Num. of seats : 5
Ford  Ranger V SuperCrew (Americas)  Raptor 3.0 EcoBoost V6 (405 Hp) 4x4 Automatic  Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban :
Fuel consumption / economy - extra urban :
Fuel consumption / economy - combined :
Fuel Type : Petrol (Gasoline)
Fuel tank volume : 77 l | 20.3 US gallons | 16.9 UK gallons
Ford  Ranger V SuperCrew (Americas)  Raptor 3.0 EcoBoost V6 (405 Hp) 4x4 Automatic  Performance Performance
Power : 405 hp | 298 kW
Max power in :
Maximum speed :
Acceleration from 0 to 100 km/h :
Torque : 583 Nm
Ford  Ranger V SuperCrew (Americas)  Raptor 3.0 EcoBoost V6 (405 Hp) 4x4 Automatic  Engine Engine
Model Engine : EcoBoost
Engine position :
Engine displacement : 2949 cm3
Fuel System :
Valvetrain : DOHC, TI-VCT
Number of cylinders : 6
Number of valves per cylinder : 4
Compression ratio : 10.5
Piston Stroke : 86 mm
Cylinder Bore : 85.4 mm
Ford  Ranger V SuperCrew (Americas)  Raptor 3.0 EcoBoost V6 (405 Hp) 4x4 Automatic  Transmission Transmission
Wheel Drive : All wheel drive (4x4)
Ford  Ranger V SuperCrew (Americas)  Raptor 3.0 EcoBoost V6 (405 Hp) 4x4 Automatic  Chassis Chassis
Length : 5357 mm | 210.9 in
Width : 2007 mm | 79.0 in
Width with mirrors folded : 2027 mm | 79.8 in
Width including mirrors : 2202 mm | 86.7 in
Height : 1928 mm | 75.9 in
Wheelbase : 3269 mm | 128.7 in
Front track : 1709 mm | 67.3 in
Rear (Back) track : 1709 mm | 67.3 in
Ride height(clearance) : 272 mm | 10.7 in
Approach angle : 33 °
Departure angle : 26.4 °
Front overhang : 861 mm
Rear overhang : 1224 mm
Minimum volume of Luggage (trunk) : 1232 l
Front suspension : Double wishbone
Max weight : 3080 kg | 6790 lbs
Kerb Weight : 2415 kg | 5324 lbs
Steering type : Steering rack and pinion
Power steering : Electric Steering
Minimum turning circle (turning diameter) : 13.2 m
Permitted trailer load with brakes (12%) : 2499 kg
Ford  Ranger V SuperCrew (Americas)  Raptor 3.0 EcoBoost V6 (405 Hp) 4x4 Automatic  Tyres / Wheels Tyres / Wheels
Tire size : 285/70 R17
Wheel rims size : 17
