Ford S-MAX II 2.0 TDCi (190 Hp) Automatic S&S technical specifications and fuel economy

Ford S-MAX II 2.0 TDCi (190 Hp) Automatic S&S

Ford S-MAX II 2.0 TDCi (190 Hp) Automatic S&S has a combined fuel consumption of 5.2-5.8 l/100 km urban fuel consumption of 6.0-6.2 l/100 km extra urban fuel consumption of 4.7-5.0 l/100 km Ford S-MAX II 2.0 TDCi (190 Hp) Automatic S&S accelerates from 0 to 100 km/h in 9.7 sec. The maximum speed is 208 km/h | 129 mph.



Ford S-MAX II 2.0 TDCi (190 Hp) Automatic S&S Technical information

  • Engine displacement
    1997 cm3
  • Power
    190 hp
    140 kW
  • Acceleration from 0 to 100 km/h
    9.7 sec
  • Maximum speed
    208 km/h
    129 mph
  • Kerb Weight
    1734 kg
    3823 lbs
Compare this car with other cars
Ford S-MAX II 2.0 TDCi (190 Hp) Automatic S&S General information General information
Brand : Ford
Model : S-MAX
Generation : S-MAX II
Engine / modification : 2.0 TDCi (190 Hp) Automatic S&S
Production start : 2018 year
Production end : 2019 year
Coupe type : MPV
Num. of Doors : 5
Num. of seats : 5
Ford S-MAX II 2.0 TDCi (190 Hp) Automatic S&S Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban : 6.0-6.2 l/100 km
Fuel consumption / economy - extra urban : 4.7-5.0 l/100 km
Fuel consumption / economy - combined : 5.2-5.8 l/100 km
Fuel Type : Diesel
Fuel tank volume : 70 l | 18.5 US gallons | 15.4 UK gallons
Emission standard : Euro 6 d-TEMP
CO2 emissions : 136-151 g/km
Ford S-MAX II 2.0 TDCi (190 Hp) Automatic S&S Performance Performance
Power : 190 hp | 140 kW
Max power in : 3500 rpm.
Maximum speed : 208 km/h | 129 mph
Acceleration from 0 to 100 km/h : 9.7 sec
Torque : 400 Nm @ 2000-3000 rpm.
Ford S-MAX II 2.0 TDCi (190 Hp) Automatic S&S Engine Engine
Engine position : Front, transverse
Engine displacement : 1997 cm3
Fuel System : Diesel Commonrail
Aspiration / Turbine : Turbocharger / Intercooler
Position of cylinders : Inline
Valvetrain : DOHC
Number of cylinders : 4
Number of valves per cylinder : 4
Compression ratio : 17
Piston Stroke : 88 mm
Cylinder Bore : 85 mm
Ford S-MAX II 2.0 TDCi (190 Hp) Automatic S&S Transmission Transmission
Wheel Drive : Front wheel drive
Number of Gears (automatic transmission) : 8
Ford S-MAX II 2.0 TDCi (190 Hp) Automatic S&S Chassis Chassis
Length : 4796 mm | 188.8 in
Width : 1916 mm | 75.4 in
Height : 1953 mm | 76.9 in
Wheelbase : 2849 mm | 112.2 in
Front track : 1606 mm | 63.2 in
Rear (Back) track : 1606 mm | 63.2 in
Ride height(clearance) : 128-150 mm
Minimum volume of Luggage (trunk) : 700/285 l
Maximum amount of Luggage (trunk) : 2200/2020 l
Front suspension : Independent, Spring McPherson, with stabilizer
Rear suspension : Independent, spring
Max weight : 2540 kg | 5600 lbs
Front brakes : Ventilated discs
Rear brakes : Disc
Kerb Weight : 1734 kg | 3823 lbs
ABS : yes
Steering type : Steering rack and pinion
Minimum turning circle (turning diameter) : 12 m
Ford S-MAX II 2.0 TDCi (190 Hp) Automatic S&S Tyres / Wheels Tyres / Wheels
Tire size : 235/55 R17; 235/50 R18; 245/45 R19
Wheel rims size : 7.5J x 17; 7.5J x 18; 8J x 19
