TVR Chimaera 5.0 (340 Hp) technical specifications and fuel economy

TVR  Chimaera  5.0 (340 Hp)

TVR Chimaera 5.0 (340 Hp) accelerates from 0 to 100 km/h in 5.5 sec. The maximum speed is 271 km/h | 168 mph.



TVR Chimaera 5.0 (340 Hp) Technical information

  • Engine displacement
    4997 cm3
  • Power
    340 hp
    250 kW
  • Acceleration from 0 to 100 km/h
    5.5 sec
  • Maximum speed
    271 km/h
    168 mph
  • Kerb Weight
    1060 kg
    2337 lbs
Compare this car with other cars
TVR  Chimaera  5.0 (340 Hp)  General information General information
Brand : TVR
Model : Chimaera
Generation : Chimaera
Engine / modification : 5.0 (340 Hp)
Production start : 1993 year
Production end : 1997 year
Coupe type : Cabriolet
Num. of Doors : 2
Num. of seats : 2
TVR  Chimaera  5.0 (340 Hp)  Fuel economy (consumption) Fuel economy (consumption)
Fuel consumption / economy - urban :
Fuel consumption / economy - extra urban :
Fuel consumption / economy - combined :
Fuel Type : Petrol (Gasoline)
Fuel tank volume : 57 l | 15.1 US gallons | 12.5 UK gallons
TVR  Chimaera  5.0 (340 Hp)  Performance Performance
Power : 340 hp | 250 kW
Max power in : 5250 rpm.
Maximum speed : 271 km/h | 168 mph
Acceleration from 0 to 100 km/h : 5.5 sec
Torque : 481 Nm/3750 rpm.
TVR  Chimaera  5.0 (340 Hp)  Engine Engine
Engine position : Front, longitudinal
Engine displacement : 4997 cm3
Fuel System : Multi-point injection
Position of cylinders : V engine
Number of cylinders : 8
Number of valves per cylinder : 2
Compression ratio : 9.5
Piston Stroke : 90 mm
Cylinder Bore : 94 mm
TVR  Chimaera  5.0 (340 Hp)  Transmission Transmission
Wheel Drive : Rear wheel drive
Number of Gears (automatic transmission) : -
Number of Gears (manual transmission) : 5
TVR  Chimaera  5.0 (340 Hp)  Chassis Chassis
Length : 3965 mm | 156.1 in
Width : 1730 mm | 68.1 in
Height : 1223 mm | 48.1 in
Wheelbase : 2282 mm | 89.8 in
Front track : 1460 mm | 57.5 in
Rear (Back) track : 1470 mm | 57.9 in
Minimum volume of Luggage (trunk) : 310 l
Front suspension : Wishbone
Rear suspension : Wishbone
Max weight : 1280 kg | 2822 lbs
Front brakes : Ventilated discs
Rear brakes : Disc
Kerb Weight : 1060 kg | 2337 lbs
ABS : yes
Steering type : Steering rack and pinion
TVR  Chimaera  5.0 (340 Hp)  Tyres / Wheels Tyres / Wheels
Tire size : 235/50 R 16
